Description
| Specification | Value |
|---|---|
| Design | Two-way bass reflex |
| HF Driver | 25 mm (1 in.) vented aluminium dome with MAT |
| LF/MF Driver | 130 mm (5.25 in.) aluminium cone |
| Frequency Range (-6dB) | 47 Hz – 20 kHz |
| Typical In-Room Bass Response (-6dB) | 42 Hz |
| Frequency Response (±3dB) | 51 Hz – 20 kHz |
| Crossover Frequency | 2.1 kHz |
| Amplifier Requirements | 10 – 150 W |
| Sensitivity (2.83V/1m) | 86 dB |
| Harmonic Distortion (90dB, 1m) | <2% above 140 Hz, <1% from 170 Hz – 20 kHz |
| Maximum Output | 108 dB |
| Impedance | 4 Ω (minimum 3.2 Ω) |
| Weight | 6.1 kg (13.4 lbs.) |
| Dimensions (H × W × D) | 302 × 180 × 277 mm (11.9 × 7.1 × 10.9 in.) |
| Finishes | Satin Black, Satin White, Walnut |
| Downloads | Q Series User Manual, Q Series Information Sheet, Q Series White Paper |
