Description
| Specification | Value |
|---|---|
| Design | Two-way bass reflex |
| HF Driver | 25 mm (1 in.) vented aluminium dome with MAT |
| LF/MF Driver | 165 mm (6.5 in.) aluminium cone |
| Frequency Range (-6dB) | 42 Hz – 20 kHz |
| Typical In-Room Bass Response (-6dB) | 39 Hz |
| Frequency Response (±3dB) | 49 Hz – 20 kHz |
| Crossover Frequency | 2.0 kHz |
| Amplifier Requirements | 15 – 150 W |
| Sensitivity (2.83V/1m) | 87 dB |
| Harmonic Distortion (90dB, 1m) | <2% above 110 Hz, <1% from 135 Hz – 20 kHz |
| Maximum Output | 109 dB |
| Impedance | 4 Ω (minimum 3.2 Ω) |
| Weight | 8.2 kg (18.1 lbs.) |
| Dimensions (H × W × D) | 357 × 210 × 305 mm (14.1 × 8.3 × 12.0 in.) |
| Finishes | Satin Black, Satin White, Walnut |
| Downloads | Q Series User Manual, Q Series Information Sheet, Q Series White Paper |
